Published September 23, 2022
Creating a PDF file in .NET MAUI Using IronPDF
Introduction
The .NET Multi-platform App UI (.NET MAUI) is a cross-platform framework for creating native mobile and desktop apps with C# and XAML. You can use the .NET MAUI app that operates on Android, iOS, MacOS, and Windows using a single code base. .NET MAUI is open-source and is an improvement of Xamarin Forms. The UI controls have been rewritten from the bottom-up for performance and extensibility. Additionally, it has been expanded from the mobile platform to include desktop use cases. If you've ever used Xamarin Forms to create cross-platform user interfaces, then you'll find that the .NET MAUI framework has a lot in common with it.
Nevertheless, there are some distinctions. You can construct multi-platform apps with the .NET MAUI Framework by using a single project, but you can add platform-specific code and resources if needed. One of the main goals of .NET MAUI is to allow you to write as much of your app logic and UI layout in a single code base as possible. .NET MAUI will be available for all platforms and will support the existing MVVM and XAML patterns.
.NET MAUI allows developers to work on various platforms such as mobile development and Windows platforms.
IronPDF Features
IronPDF is a powerful PDF converter that can handle almost any task that a browser can handle. The .NET library for developers makes it simple to create, read, and manipulate PDF files. IronPDF uses the Google Chrome engine to convert HTML to PDF files. Among other web technologies, IronPDF supports HTML, ASPX, Razor HTML, and MVC View. IronPDF supports the Microsoft .NET applications (both ASP.NET Web applications and traditional Windows applications). IronPDF can also be used to make attractive PDF documents.
IronPDF allows us to create PDF files from HTML files containing JavaScript, CSS, and image files.
Not only can HTML files be converted to PDF, but we can also convert image files to PDF.
IronPDF can help us create interactive PDF documents, fill out and submit interactive forms, merge and split PDF documents, extract text and images from PDF documents, search text in PDF documents, rasterize PDF pages to images, convert PDF to HTML, and print PDF documents.
IronPDF can generate a document from a URL. For login behind HTML login forms, it also allows the use of custom network login credentials, user agents, proxies, cookies, HTTP headers, and form variables.
IronPDF is a library that allows us to read and fill in PDF documents and is capable of extracting images from documents. It allows us to add headers, footers, text, photos, bookmarks, watermarks, and more to documents. It also allows us to join and split pages in a new or existing document. IronPDF is capable of converting documents to PDF objects without using an Acrobat viewer. It is also possible to convert a CSS file to a PDF document and CSS media-type files can be converted into documents.
You can download the software product from this link.
How to Create a PDF File in .NET MAUI
- Create a new .NET MAUI PDF Project in Visual Studio
- Install the IronPDF Library using NuGet
- Design the UI of the .NET MAUI Content Pages
- Use the
ChromePdfRenderer.RenderHtmlAsPdf
method to generate a PDF File - Save the PDF file to users' devices with platform-specific code.
Creating a New Project in Visual Studio
We can create a project using both Visual Studio Code and Visual Studio. When using Visual Studio Code, we need to use the command-line tool to install the project type template.
Open the Microsoft Visual Studio software and go to the File menu. Select "new project", and in the new project window select ".NET MAUI project". In this article, we are going to use a .NET MAUI app to generate PDF documents and save them to a suitable location.

Enter the project name and select the file path in the appropriate text box. Then, click the create button, as in the screenshot below.

The Visual Studio project will now generate the structure for the selected application, and as we have selected the .NET MAUI app platform, it will now open the MainPage.cs file where we can enter the code and build/run the application. We need to select the required platform to build the application.

Next, we can add the library to test the code.
Install the IronPDF Library
The IronPDF Library can be downloaded and installed in four ways.
These are:
- Using Visual Studio.
- Using the Visual Studio Command-Line.
- Direct download from the NuGet website.
- Direct download from the IronPDF website.
Using Visual Studio
The Visual Studio software provides the NuGet Package manager option to install the package directly to the solution. The below screenshot shows how to open the NuGet Package Manager.

This provides the search box to show the list of packages from the NuGet website. In the Package Manager, we need to search for the keyword "IronPDF," as in the screenshot below.

In the above image, we can see the list of the related search items. We need to select the required option to install the package to the solution. Once we have selected the download option, it will be installed on all the .NET MAUI application platforms such as the Android, iOS, and Windows platforms.
Using the Visual Studio Command-Line
In Visual Studio, go to Tools-> NuGet Package Manager -> Package manager console
Enter the following line in the package manager console tab: Install-Package IronPDF
Now, the package will download/install to all the .NET MAUI platforms on the current project and be ready to use.

Direct Download from the NuGet Website
The third way is to download the NuGet package directly from their website. Click this link to go to the NuGet IronPDF repository page.
- Select the download package option from the menu on the right-hand side.
- Double-click the downloaded package. It will be installed automatically.
- Reload the solution and the package should be usable in your project.
Direct Download from the IronPDF Website
Click the link here to download the latest package directly from the website. Once downloaded, follow the steps below to add the package to your project.
- Right-click the Dependencies option for the project from the solution window.
- Select the specific platform, then select the options reference and browse the location of the downloaded reference.
- Click OK to add the reference.
You will also need to add references to all the .NET MAUI-supported platforms.
Create PDFs on a .NET MAUI app using IronPDF
When a project is created, there will be an auto-generated file called MainPage.XAML. This is where we can design the UI of the .NET MAUI application.
We will use the code below.
<?xml version="1.0" encoding="utf-8" ?>
<ContentPage xmlns="http://schemas.microsoft.com/dotnet/2021/maui"
xmlns:x="http://schemas.microsoft.com/winfx/2009/xaml"
x:Class="MAUI_PDF.MainPage"
>
<ScrollView>
<VerticalStackLayout
Spacing="25"
Padding="30,0"
VerticalOptions="Center">
<Image
Source="dotnet_bot.png"
SemanticProperties.Description="Cute dot net bot waving hi to you!"
HeightRequest="200"
HorizontalOptions="Center" />
<Label
Text="Welcome to IronPDF!"
SemanticProperties.HeadingLevel="Level1"
FontSize="32"
HorizontalOptions="Center" />
<Button
x:Name="PdfBtn"
Text="Click me to generate PDF"
SemanticProperties.Hint="Click button to generate PDF"
Clicked="GeneratePDF"
HorizontalOptions="Center" />
</VerticalStackLayout>
</ScrollView>
</ContentPage>
Once we have added the above code to the MainPage.XAML file, open the MainPage.XAML.cs file and include the following method inside of the MainPage class:
private void GeneratePDF(object sender, EventArgs e)
{
ChromePdfRenderer renderer = new ChromePdfRenderer();
var doc = renderer.RenderHtmlAsPdf("<h1>Hello IronPDF!</h1> <p>I'm using IronPDF MAUI!</p>");
//Saves the memory stream as file.
SaveService saveService = new SaveService();
saveService.SaveAndView("IronPDF HTML string.pdf", "application/pdf", doc.Stream);
}
private void GeneratePDF(object sender, EventArgs e)
{
ChromePdfRenderer renderer = new ChromePdfRenderer();
var doc = renderer.RenderHtmlAsPdf("<h1>Hello IronPDF!</h1> <p>I'm using IronPDF MAUI!</p>");
//Saves the memory stream as file.
SaveService saveService = new SaveService();
saveService.SaveAndView("IronPDF HTML string.pdf", "application/pdf", doc.Stream);
}
Private Sub GeneratePDF(ByVal sender As Object, ByVal e As EventArgs)
Dim renderer As New ChromePdfRenderer()
Dim doc = renderer.RenderHtmlAsPdf("<h1>Hello IronPDF!</h1> <p>I'm using IronPDF MAUI!</p>")
'Saves the memory stream as file.
Dim saveService As New SaveService()
saveService.SaveAndView("IronPDF HTML string.pdf", "application/pdf", doc.Stream)
End Sub
The GeneratePDF
method generates a new PDF document containing the text "Hello, IronPDF!..." and saves it on the users' computer at a specified location.
In the method above, we create a new ChromePdfRenderer object and invoke the RenderHtmlAsPdf method to produce a new PDF document containing the words "Hello IronPDF! ..." from a string of HTML markup. Next, we delegate the saving of the file on the user's device to a separate class, called SaveService. We will create this class in the next step.
The complete MainPage.XAML.cs file is given below. Please ensure that the file contents matches what's shown below before continuing to the next step:
// Change the namespace as desired, but make sure that all source files use this same namespace,
// or there will be errors!
namespace MAUI_IronPDF;
// This namespace is required to make use of IronPDF functionality
using IronPdf;
public partial class MainPage : ContentPage
{
public MainPage()
{
InitializeComponent();
}
private void GeneratePDF(object sender, EventArgs e)
{
ChromePdfRenderer renderer = new ChromePdfRenderer();
var doc = renderer.RenderHtmlAsPdf("<h1>Hello IronPDF!</h1> <p>I'm using IronPDF MAUI!</p>");
//Saves the memory stream as file.
SaveService saveService = new SaveService();
saveService.SaveAndView("IronPDF HTML string.pdf", "application/pdf", doc.Stream);
}
}
// Change the namespace as desired, but make sure that all source files use this same namespace,
// or there will be errors!
namespace MAUI_IronPDF;
// This namespace is required to make use of IronPDF functionality
using IronPdf;
public partial class MainPage : ContentPage
{
public MainPage()
{
InitializeComponent();
}
private void GeneratePDF(object sender, EventArgs e)
{
ChromePdfRenderer renderer = new ChromePdfRenderer();
var doc = renderer.RenderHtmlAsPdf("<h1>Hello IronPDF!</h1> <p>I'm using IronPDF MAUI!</p>");
//Saves the memory stream as file.
SaveService saveService = new SaveService();
saveService.SaveAndView("IronPDF HTML string.pdf", "application/pdf", doc.Stream);
}
}
Imports IronPdf
' Change the namespace as desired, but make sure that all source files use this same namespace,
' or there will be errors!
Namespace MAUI_IronPDF
' This namespace is required to make use of IronPDF functionality
Partial Public Class MainPage
Inherits ContentPage
Public Sub New()
InitializeComponent()
End Sub
Private Sub GeneratePDF(ByVal sender As Object, ByVal e As EventArgs)
Dim renderer As New ChromePdfRenderer()
Dim doc = renderer.RenderHtmlAsPdf("<h1>Hello IronPDF!</h1> <p>I'm using IronPDF MAUI!</p>")
'Saves the memory stream as file.
Dim saveService As New SaveService()
saveService.SaveAndView("IronPDF HTML string.pdf", "application/pdf", doc.Stream)
End Sub
End Class
End Namespace
Now, create a new class file called SaveService.cs in the root of the project and add the following source code:
// Change the namespace as desired, but make sure that all source files use this same namespace,
// or there will be errors!
namespace MAUI_IronPDF
{
// SaveService partial class declaration ... this allows a layer of abstraction
// as we implement the save file details specially for each platform on which this app will
// operate!
public partial class SaveService
{
public void SaveAndView(string filename, string contentType, MemoryStream stream)
{
SaveFile(filename, contentType, stream);
}
// Additional partial files will provide implementations for this method specifically.
partial void SaveFile(string filename, string contentType, MemoryStream stream);
}
}
// Change the namespace as desired, but make sure that all source files use this same namespace,
// or there will be errors!
namespace MAUI_IronPDF
{
// SaveService partial class declaration ... this allows a layer of abstraction
// as we implement the save file details specially for each platform on which this app will
// operate!
public partial class SaveService
{
public void SaveAndView(string filename, string contentType, MemoryStream stream)
{
SaveFile(filename, contentType, stream);
}
// Additional partial files will provide implementations for this method specifically.
partial void SaveFile(string filename, string contentType, MemoryStream stream);
}
}
' Change the namespace as desired, but make sure that all source files use this same namespace,
' or there will be errors!
Namespace MAUI_IronPDF
' SaveService partial class declaration ... this allows a layer of abstraction
' as we implement the save file details specially for each platform on which this app will
' operate!
Partial Public Class SaveService
Public Sub SaveAndView(ByVal filename As String, ByVal contentType As String, ByVal stream As MemoryStream)
SaveFile(filename, contentType, stream)
End Sub
' Additional partial files will provide implementations for this method specifically.
Partial Private Sub SaveFile(ByVal filename As String, ByVal contentType As String, ByVal stream As MemoryStream)
End Sub
End Class
End Namespace
Since the implementation details for saving content on user devices varies with each platform (Windows, Android, MacOS, etc), it is necessary to write platform-specific code for each device type which the application will support. To make this possible, we define SaveService
as a partial class (for abstraction purposes) containing one partial method, called SaveAndView
. Following this, the implementation of this method will be defined in separate SaveService.cs partial class for one or more of the folders nested in the Platforms folder within the Solutions Explorer (see image below):

For simplicity, this tutorial will be defining the aformentioned partial file for the Windows platform only. Create a new SaveService.cs file under the Windows platform folder containing the code shown below:
using Windows.Storage;
using Windows.Storage.Pickers;
using Windows.Storage.Streams;
using Windows.UI.Popups;
namespace MAUI_IronPDF;
public partial class SaveService
{
async partial void SaveFile(string filename, string contentType, MemoryStream stream)
{
StorageFile stFile;
string extension = Path.GetExtension(filename);
//Gets process windows handle to open the dialog in application process.
IntPtr windowHandle = System.Diagnostics.Process.GetCurrentProcess().MainWindowHandle;
if (!Windows.Foundation.Metadata.ApiInformation.IsTypePresent("Windows.Phone.UI.Input.HardwareButtons"))
{
//Creates file save picker to save a file.
FileSavePicker savePicker = new();
savePicker.DefaultFileExtension = ".pdf";
savePicker.SuggestedFileName = filename;
//Saves the file as Pdf file.
savePicker.FileTypeChoices.Add("PDF", new List<string>() { ".pdf" });
WinRT.Interop.InitializeWithWindow.Initialize(savePicker, windowHandle);
stFile = await savePicker.PickSaveFileAsync();
}
else
{
StorageFolder local = ApplicationData.Current.LocalFolder;
stFile = await local.CreateFileAsync(filename, CreationCollisionOption.ReplaceExisting);
}
if (stFile != null)
{
using (IRandomAccessStream zipStream = await stFile.OpenAsync(FileAccessMode.ReadWrite))
{
//Writes compressed data from memory to file.
using Stream outstream = zipStream.AsStreamForWrite();
outstream.SetLength(0);
//Saves the stream as file.
byte[] buffer = stream.ToArray();
outstream.Write(buffer, 0, buffer.Length);
outstream.Flush();
}
//Create message dialog box.
MessageDialog msgDialog = new("Do you want to view the document?", "File has been created successfully");
UICommand yesCmd = new("Yes");
msgDialog.Commands.Add(yesCmd);
UICommand noCmd = new("No");
msgDialog.Commands.Add(noCmd);
WinRT.Interop.InitializeWithWindow.Initialize(msgDialog, windowHandle);
//Showing a dialog box.
IUICommand cmd = await msgDialog.ShowAsync();
if (cmd.Label == yesCmd.Label)
{
//Launch the saved file.
await Windows.System.Launcher.LaunchFileAsync(stFile);
}
}
}
}
using Windows.Storage;
using Windows.Storage.Pickers;
using Windows.Storage.Streams;
using Windows.UI.Popups;
namespace MAUI_IronPDF;
public partial class SaveService
{
async partial void SaveFile(string filename, string contentType, MemoryStream stream)
{
StorageFile stFile;
string extension = Path.GetExtension(filename);
//Gets process windows handle to open the dialog in application process.
IntPtr windowHandle = System.Diagnostics.Process.GetCurrentProcess().MainWindowHandle;
if (!Windows.Foundation.Metadata.ApiInformation.IsTypePresent("Windows.Phone.UI.Input.HardwareButtons"))
{
//Creates file save picker to save a file.
FileSavePicker savePicker = new();
savePicker.DefaultFileExtension = ".pdf";
savePicker.SuggestedFileName = filename;
//Saves the file as Pdf file.
savePicker.FileTypeChoices.Add("PDF", new List<string>() { ".pdf" });
WinRT.Interop.InitializeWithWindow.Initialize(savePicker, windowHandle);
stFile = await savePicker.PickSaveFileAsync();
}
else
{
StorageFolder local = ApplicationData.Current.LocalFolder;
stFile = await local.CreateFileAsync(filename, CreationCollisionOption.ReplaceExisting);
}
if (stFile != null)
{
using (IRandomAccessStream zipStream = await stFile.OpenAsync(FileAccessMode.ReadWrite))
{
//Writes compressed data from memory to file.
using Stream outstream = zipStream.AsStreamForWrite();
outstream.SetLength(0);
//Saves the stream as file.
byte[] buffer = stream.ToArray();
outstream.Write(buffer, 0, buffer.Length);
outstream.Flush();
}
//Create message dialog box.
MessageDialog msgDialog = new("Do you want to view the document?", "File has been created successfully");
UICommand yesCmd = new("Yes");
msgDialog.Commands.Add(yesCmd);
UICommand noCmd = new("No");
msgDialog.Commands.Add(noCmd);
WinRT.Interop.InitializeWithWindow.Initialize(msgDialog, windowHandle);
//Showing a dialog box.
IUICommand cmd = await msgDialog.ShowAsync();
if (cmd.Label == yesCmd.Label)
{
//Launch the saved file.
await Windows.System.Launcher.LaunchFileAsync(stFile);
}
}
}
}
Imports Windows.Storage
Imports Windows.Storage.Pickers
Imports Windows.Storage.Streams
Imports Windows.UI.Popups
Namespace MAUI_IronPDF
Partial Public Class SaveService
Private Async Sub SaveFile(ByVal filename As String, ByVal contentType As String, ByVal stream As MemoryStream)
Dim stFile As StorageFile
Dim extension As String = Path.GetExtension(filename)
'Gets process windows handle to open the dialog in application process.
Dim windowHandle As IntPtr = System.Diagnostics.Process.GetCurrentProcess().MainWindowHandle
If Not Windows.Foundation.Metadata.ApiInformation.IsTypePresent("Windows.Phone.UI.Input.HardwareButtons") Then
'Creates file save picker to save a file.
Dim savePicker As New FileSavePicker()
savePicker.DefaultFileExtension = ".pdf"
savePicker.SuggestedFileName = filename
'Saves the file as Pdf file.
savePicker.FileTypeChoices.Add("PDF", New List(Of String)() From {".pdf"})
WinRT.Interop.InitializeWithWindow.Initialize(savePicker, windowHandle)
stFile = Await savePicker.PickSaveFileAsync()
Else
Dim local As StorageFolder = ApplicationData.Current.LocalFolder
stFile = Await local.CreateFileAsync(filename, CreationCollisionOption.ReplaceExisting)
End If
If stFile IsNot Nothing Then
Using zipStream As IRandomAccessStream = Await stFile.OpenAsync(FileAccessMode.ReadWrite)
'Writes compressed data from memory to file.
Using outstream As Stream = zipStream.AsStreamForWrite()
outstream.SetLength(0)
'Saves the stream as file.
Dim buffer() As Byte = stream.ToArray()
outstream.Write(buffer, 0, buffer.Length)
outstream.Flush()
End Using
End Using
'Create message dialog box.
Dim msgDialog As New MessageDialog("Do you want to view the document?", "File has been created successfully")
Dim yesCmd As New UICommand("Yes")
msgDialog.Commands.Add(yesCmd)
Dim noCmd As New UICommand("No")
msgDialog.Commands.Add(noCmd)
WinRT.Interop.InitializeWithWindow.Initialize(msgDialog, windowHandle)
'Showing a dialog box.
Dim cmd As IUICommand = Await msgDialog.ShowAsync()
If cmd.Label = yesCmd.Label Then
'Launch the saved file.
Await Windows.System.Launcher.LaunchFileAsync(stFile)
End If
End If
End Sub
End Class
End Namespace
Build and run the MAUI application. A window will appear containing the interface shown below:

Click on the "Generate PDF" button. After a few moments, a popup will appear that allows us to choose the location of the generated PDF file.

Conclusion
IronPDF is one of the most commonly used PDF-converter libraries that allows you to generate, read, edit, and format PDFs. The IronPDF library provides many benefits and functionality, including a browser engine that will help to convert a given URL into a PDF file, allows you to add CSS to HTML strings and convert them to PDF files, and also allows you to fill out PDF forms. All of the features of IronPDF are included in one library.
IronPDF comes with various price structures. The basic price for IronPDF starts at $749. Product support and updates are also available for a one-year fee. Royalty-free redistribution coverage can also be purchased as an add-on.
To summarize, we recommend IronPDF since it offers great performance and a large number of features for developers working with PDFs. It supports universal platforms such as .NET MAUI. It also comes with excellent assistance and documentation, allowing you to fully utilize the wide range of the IronPDF library and its many features.
